Industrial ­chippers

Heinola Sawmill Machinery has a hundred-year tradition in manufacturing chippers. We offer extremely durable, high-quality chippers with excellent chip quality.

Chippers with slope infeedChippers with slope infeed
Chippers with feeding devicesChippers with feeding devices
Mobile chippersMobile chippers

Our high-quality chippers are simple, reliable, long-lasting, and produce top-quality chips

THE HEINOLA chipper product family includes chippers for sawmills, the veneer and plywood industry, the pulp and paper industry as well as for bioenergy production. The HEINOLA chippers are well known for their low operating costs, long life, effciency and excellent chip quality.

The characteristics of chippers, such as the diameter of the knife drum, the size of the feed opening, the type of feed mechanism, motor power, as well as the number and speed of the knives, significantly affect the quality of the chips. Consistency is especially crucial for the pulp industry.

High yield

The chips produced by HEINOLA chippers meet the pulp and energy industry’s strict quality requirements. They have a high yield because the quantity of fine fraction is small. The chip quality is produced by the chipper, not by the screen.

Teollisuushakkuri 137rse



HEINOLA chippers (pdf)HEINOLA chippers (pdf)
Chippers with slope infeedChippers with slope infeed
Chippers with feeding devicesChippers with feeding devices
Mobile chippersMobile chippers

Why Choose HEINOLA Industrial chippers?

  • We offer comprehensive spare parts service with fast delivery.
  • Maintenance and repair services are available directly from the manufacturer.
  • Over 50 years of experience in chipper manufacturing.
  • Our chippers have a highly durable structure.
  • The end product is high-quality and consistent chips.

Chippers with slope infeed

HEINOLA 75 RSE

Chipper with horizontal infeed for chipping sawmill slabs, edgings and trim ends.

Drum diameter

700 mm

Infeed opening, width

570 mm

Infeed opening, height

265 mm

Number of knives

4

Required power

45–110 kW

Capacity

20–80 m3/h

Infeed device with pneumatically relieved infeed roll with drive above

Weight

approx. 3500 kg

HEINOLA 97 RSVE

Chipper with horizontal infeed for chipping sawmill slabs, edgings and trim ends, especially suitable for chipping material with lots of short trim ends.

Drum diameter

900 mm

Infeed opening, width

660 mm

Infeed opening, height

330 mm

Number of knives

4/6 pcs

Required power

75–160 kW

Capacity

40–110 m3/h

Feeding device with rolls; 5 rolls with drive and pneumatically relieved roller unit’s upper part

Weight

approx. 5500 kg

HEINOLA 137 RSE

Chipper with horizontal infeed for chipping large amounts of sawmill slabs, edgings and cut-offs.

Drum diameter

1300 mm

Infeed opening, width

700 mm

Infeed opening, height

435 mm

Number of knives

4/6 pcs

Required power

160–500 kW

Capacity

100–300 m3/h

Infeed device with a pneumatically relieved infeed roller above and 3 infeed rolls with drive below

Weight

approx. 10,000 kg

HEINOLA 1310 RSE

Chipper with horizontal infeed for chipping tree trunks and logs for the energy industry, e.g. for  chipping stations. Especially suitable for chipping pulpwood for the pulp industry and as a pre-processing machine for the pellet factories.

Drum diameter

1 300 mm

Infeed opening, width

1 000 mm

Infeed opening, height

730 mm

Number of knives

2 pcs

Required power

270–630 kW

Capacity

150–350 m3/h

Infeed device with 3 hydraulic rolls below and a hydraulic infeed roller with hydraulic relief above

Weight

approx. 11 000 kg

HEINOLA 910 RSV

Veneer chipper with horizontal infeed for chipping veneer mill waste, veneer cores and plywood edgings.

Drum diameter

900 mm

Infeed opening, width

1 000 mm

Infeed opening, height

400 mm

Number of knives

4 pcs

Required power

100–315 kW

Capacity

100–250 m3/h

Infeed device with 3 rolls with drive below, 4 rolls with drive and pneumatic relief and 1 pre-pressing roll with drive above

Weight

approx. 10 300 kg

Heinola 97 RSE

Vaakasyöttöinen hakkuri sahojen pintalautojen ja rimojen sekä tasauspätkien haketukseen.

Rummun halkaisija

900 mm

Syöttöaukon leveys

660 mm

Syöttöaukon korkeus

330 mm

Terien lukumäärä

4/6 kpl

Tehontarve

75–160 kW

Hakkeen määrä

40–110 m3/h

Syöttölaite, jossa pneumaattisesti kevennetty käytöllinen yläsyöttötela

Paino

noin 5 200 kg

Chippers with feeding devices

HEINOLA 97 RE

Chipper with slope infeed for chipping dry and green cut-offs.

Drum diameter

900 mm

Infeed opening, width

680 mm

Infeed opening, height

440/580 mm

Number of knives

4/6 pcs

Required power

75–160 kW

Capacity

40–110 m3/h

Weight

approx. 4 500 kg

HEINOLA 137 RE

Chipper with slope infeed for chipping dry and green cut-offs. An excellent choice for chipping the pulp and papers industry’s irregularly-sized pieces and the veneer and plywood industry’s trim ends.

Drum diameter

1 300 mm

Infeed opening, width

770 mm

Infeed opening, height

750 mm

Number of knives

4/6 pcs

Required power

160–500 kW

Capacity

100–300 m3/h

Weight

approx. 6 500 kg

Mobile chippers

HEINOLA 1310 TRUCK

The highly efficient chipping unit HEINOLA 1310 TRUCK produces consistent quality energy chips from logging residues, thinning wood, logs, and slabs.

Drum diameter

1300 mm

Infeed opening, width

1000 mm

Infeed opening, height

750 mm

Number of knives

2 pcs

Maximum log diameter

700 mm

Maximum capacity

400 i-m3/h

Weight

approx. 31 000 kg

Required power

370–600 kW

HEINOLA 1014 TRUCK

The highly efficient chipping unit HEINOLA 1014 TRUCK produces consistent quality energy chips from logging residues, thinning wood, logs, and slabs.

Drum diameter

1000 mm

Infeed opening, width

1400 mm

Infeed opening, height

720 mm

Number of knives

2+2 pcs

Maximum log diameter

540 mm

Maximum capacity

350 i-m3/h

Weight

approx. 30 000 kg

Required power

370–600 kW

HEINOLA 910 TRUCK

The highly efficient chipping unit HEINOLA 910 TRUCK produces consistent quality energy chips from logging residues, thinning wood, logs, and slabs.

Drum diameter

900 mm

Infeed opening, width

1000 mm

Infeed opening, height

720 mm

Number of knives

2 pcs

Maximum capacity

300 im3/h

Required power

300-570 kw

Suitability of chippers in different operating environments

  • HEINOLA chippers are designed for chipping surfaces, slats, and trimming waste in sawmills. We offer a variety of chipper models in different sizes and equipped with various feeding devices.
  • For the plywood industry’s waste veneers and cores, specialized chippers have been developed to produce high-quality pulp chips. HEINOLA chippers also efficiently chip edge trimmings.
  • Large chute-fed drum chippers are suitable for chipping trim waste in the pulp and paper industry.
  • HEINOLA offers powerful models ideal for chip stations, capable of producing high-quality fuel chips from whole trees and logs. Chippers can also produce chips that meet the quality requirements of the pulp industry from debarked logs.
HEINOLA chippers (pdf)HEINOLA chippers (pdf)

Key Features of HEINOLA industrial chippers

  • Our chippers are equipped with a toothed belt, which reduces the risk of fire.
  • The counter-knife beam is equipped with a shear bolt that protects the chipper, and it also ensures good maintainability.
  • The drive motor is mounted on rails, making it easy to align.
  • The feed mechanism can be easily replaced if necessary.
  • The chippers are durable and well-sealed, ensuring they do not leak.

As a supplier of wood chippers, we also take responsibility and sustainability seriously

  • In the design and manufacturing of chippers, we prioritize energy efficiency.
  • More efficient chippers reduce energy consumption and carbon footprint.
  • More efficient cutting mechanisms and recycling systems reduce waste and increase production efficiency.
  • The chippers are designed with user safety in mind, featuring automatic safety systems and high-quality user training.
  • The chippers are designed to be durable and repairable, which reduces environmental impact.
  • The chippers are durable and easily recyclable, reducing waste and environmental impact.

Contact us

Lasting HEINOLA chippers effciently produce top-quality chips which easily meet the quality criteria of the pulp and energy industries
